EDS84DMOTPBUS EN 3.0 - 11/2011 L 93
Communication manual 8400 motec PROFIBUS
DIP switch positions for setting the station address
14 DIP switch positions for setting the station address
The station address results from the sum of the binary valencies of the switches 1 ... 64.
The following table shows the switch positions for the valid address range 0 ... 126.
Setting the station address
( 31)
Station address DIP switch
64 32 16 8 4 2 1
0 OFF OFF OFF OFF OFF OFF OFF
1 OFF OFF OFF OFF OFF OFF ON
2 OFF OFF OFF OFF OFF ON OFF
3 OFF OFF OFF OFF OFF ON ON
4OFFOFFOFFOFFON OFF OFF
5 OFF OFF OFF OFF ON OFF ON
6OFFOFFOFFOFFON ON OFF
7 OFF OFF OFF OFF ON ON ON
8OFFOFFOFFON OFF OFF OFF
9 OFF OFF OFF ON OFF OFF ON
10 OFF OFF OFF ON OFF ON OFF
11 OFF OFF OFF ON OFF ON ON
12 OFF OFF OFF ON ON OFF OFF
13 OFF OFF OFF ON ON OFF ON
14 OFF OFF OFF ON ON ON OFF
15 OFF OFF OFF ON ON ON ON
16 OFF OFF ON OFF OFF OFF OFF
17 OFF OFF ON OFF OFF OFF ON
18 OFF OFF ON OFF OFF ON OFF
19 OFF OFF ON OFF OFF ON ON
20 OFF OFF ON OFF ON OFF OFF
21 OFF OFF ON OFF ON OFF ON
22 OFF OFF ON OFF ON ON OFF
23 OFF OFF ON OFF ON ON ON
24 OFF OFF ON ON OFF OFF OFF
25 OFF OFF ON ON OFF OFF ON
26 OFF OFF ON ON OFF ON OFF
27 OFF OFF ON ON OFF ON ON
28 OFF OFF ON ON ON OFF OFF
29 OFF OFF ON ON ON OFF ON
30 OFF OFF ON ON ON ON OFF
31 OFF OFF ON ON ON ON ON
32 OFF ON OFF OFF OFF OFF OFF
33 OFF ON OFF OFF OFF OFF ON
34 OFF ON OFF OFF OFF ON OFF
35 OFF ON OFF OFF OFF ON ON
36 OFF ON OFF OFF ON OFF OFF
37 OFF ON OFF OFF ON OFF ON
