Communication manual 8400 motec PROFIBUS
Commissioning
Possible settings via DIP switch
6.3.2 Setting the station address
If there are several networked PROFIBUS stations, the station addresses must differ from
each other.
The station address can be set via the DIP switches 1 ... 64 or via the »Engineer« with code
C13899
.
If the station address is to be set via C13899
, the DIP switches 1 ... 64 must be set to OFF.
DIP switch settings
The package labelling indicates the valencies of the individual DIP switches for setting the
station address.
Example:
 The current address set with the switches is displayed in C13920
.
 The station address active at the PROFIBUS is displayed in C13864
.
DIP switch positions for setting the station address
( 93)
 Note!
• The valid address range is 0 ... 126 (max. 125 slaves).
• If all DIP switches 64 ... 1 = ON, the address saved last will be used.
DIP switch Station address
S 64 32 16 8 4 2 1
OFF ... ... ... ... ... ... ... Autom. via master
ON OFF OFF OFF OFF OFF OFF OFF Value from C13899
ON OFF OFF OFF OFF OFF OFF ON 1
ON ... ... ... ... ... ... ... ...
ON ON ON ON ON ON ON OFF 126
ON ON ON ON ON ON ON ON Address saved last
DIP switch 64 32 16 8 4 2 1
Switch position OFF OFF ON OFF ON ON ON
Value 00
16 0 4 2 1
Station address = sum of the valencies = 16 + 4 + 2 + 1 = 23
