Lenze E84DGFCp Series User Manual

EDS84DMOTPBUS EN 3.0 - 11/2011 L 87
Communication manual 8400 motec PROFIBUS
Parameter reference
Parameters relevant for PROFIBUS communication
C13887
C13899
C13900
C13901
C13902
Parameter | Name:
C13887 | Suppress signalling diag. mess.
Data type: BITFIELD_8
Index: 10688
d
= 29C0
h
From version 02.00
Bit coded selection of the error responses in the drive unit, at which diagnostic signalling is suppressed.
Value is bit-coded: Info
Bit 0 Error
Bit 1 Trouble
Bit 2 Reserved
Bit 3 Warning locked
Bit 4 Reserved
... ...
Bit 7 Reserved
; Read access ; Write acces  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13899 | Station address
Data type: UNSIGNED_8
Index: 10676
d
= 29B4
h
Optional setting of the station address (instead of setting via DIP switches 1 ... 64)
• The station address set here only becomes effective if the DIP switch S has been set to ON and the DIP switches
1 ... 64 have been set to OFF prior to power-on.
• The active station address is displayed under C13864
.
• The changed station address will only be effective after the parameter set has been saved followed by a
subsequent mains switching of the communication unit or controller.
Setting the station address
( 31)
Setting range (min. value | unit | max. value) Lenze setting
3 126 3
; Read access ; Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX ; COM  MOT
Parameter | Name:
C13900 | Firmware product type
Data type: VISIBLE_STRING
Index: 10675
d
= 29B3
h
Display of the product type (string with a length of 8 bytes)
• The following identification code is displayed: "E84DGFCP".
; Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13901 | Firmware compilation date
Data type: VISIBLE_STRING
Index: 10674
d
= 29B2
h
Display of the compilation date of the firmware (string with a length of 20 bytes)
• The date ("MMM DD YYYY") and time ("hh:mm:ss") are displayed, e.g. "Mar 21 2005 12:31:21".
; Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13902 | Firmware version
Data type: VISIBLE_STRING
Index: 10673
d
= 29B1
h
Display of the firmware version (string with a length of 5 bytes)
• An identification code is displayed, e.g. "00.80".
; Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
