Communication manual 8400 motec PROFIBUS
Parameter reference
Parameters relevant for PROFIBUS communication
86 L EDS84DMOTPBUS EN 3.0 - 11/2011
C13882
C13885
C13886
Parameter | Name:
C13882 | Monitoring time: Watchdog
Data type: UNSIGNED_32
Index: 10693
d
= 29C5
h
Display of the watchdog monitoring time determined by the PROFIBUS master
• A change in the watchdog monitoring time is immediately effective.
• Monitoring starts with the receipt of the first telegram.
• When a value of "0" is displayed, the monitoring function is deactivated.
Permanent interruption of PROFIBUS communication
( 69)
Display area (min. value | unit | max. value)
0 ms 4294967295
Subcodes Info
C13882/1 Watchdog monitoring time
C13882/2 DP-V1 MSAC2
; Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13885 | Delete process data
Data type: UNSIGNED_8
Index: 10690
d
= 29C2
h
Selection of the process data which the controller will process in the event of a PROFIBUS failure in order to maintain
internal communication.
Selection list (Lenze setting printed in bold)
0 Use of most recent master PDOs
1 PDOs are set to the value 0'
; Read access ; Write acces  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13886 | Set ext. diagnostic bit in case of
Data type: BITFIELD_8
Index: 10689
d
= 29C1
h
Bit-coded selection of the error responses in the drive unit causing the external diagnostic bit ("diag bit") to be set
(see PROFIBUS specification; bit 3 of byte 1 of the DP diagnostic messages).
• The diagnostic bit is sent to the PROFIBUS master by the communication unit and is evaluated separately there.
• The diagnostic bit is always set when a system error or an error message by the safety module occurs.
• The Lenze setting "0" means that the diagnostic bit is not set for the following error responses.
Value is bit-coded:
Bit 0 Error
Bit 1 Reserved
Bit 2 Reserved
Bit 3 Warning locked
Bit 4 Reserved
... ...
Bit 7 Reserved
; Read access ; Write acces  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
