Lenze E84DGFCp Series User Manual

EDS84DMOTPBUS EN 3.0 - 11/2011 L 85
Communication manual 8400 motec PROFIBUS
Parameter reference
Parameters relevant for PROFIBUS communication
C13866
C13867
C13880
C13881
Parameter | Name:
C13866 | Display: Most recent CFG data
Data type: OCTET_STRING
Index: 10709
d
= 29D5
h
Display of the last configuration data sent by the PROFIBUS master with the "Chk-Cfg" telegram (ASCII string with
22 characters)
; Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13867 | Display: Most recent diagnostic data
Data type: OCTET_STRING
Index: 10708
d
= 29D4
h
Display of the last diagnostic data sent to the PROFIBUS master (ASCII string with 16 characters)
; Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13880 | Reaction on communication failure
Data type: UNSIGNED_8
Index: 10695
d
= 29C7
h
Monitoring response to a communication fault on the PROFIBUS
• A change in the monitoring response is effective immediately.
Permanent interruption of PROFIBUS communication
( 69)
Selection list
0 No response
1 Error
4 Warning locked
Subcodes Lenze setting Info
C13880/1 0: No response The response set here for the "watchdog/data exchange"
monitoring is executed if the bus station ...
• does not receive a message from the master within
the watchdog monitoring time (during an active
connection displayed under C13882/1
).
• detects that it is no longer in the "Data_Exchange"
state. Please see also the notes given under C13881
.
; Read access ; Write acces  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13881 | Monitoring time: Data exchange
Data type: UNSIGNED_16
Index: 10694
d
= 29C6
h
If the "Data_Exchange" state has been exited, the response parameterised with C13880/1 is carried out when the
monitoring time set here for the data exchange has expired.
• A value of "65535" in this code deactivates the monitoring function.
• A change in monitoring is effective immediately.
• The value set here for the monitoring time must be smaller than the watchdog monitoring time (displayed under
C13882/1
).
Permanent interruption of PROFIBUS communication
( 69)
Setting range (min. value | unit | max. value) Lenze setting
0 ms 65535 65535 ms
; Read access ; Write acces  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
