Lenze E84DGFCp Series User Manual

Communication manual 8400 motec PROFIBUS
Parameter reference
Table of attributes
90 L EDS84DMOTPBUS EN 3.0 - 11/2011
Table of attributes
Code Name Index Data Access
dec hex DS DA Data type Factor R W CINH
C13850
All words to master 10725 29E5 A 8 UNSIGNED_16 1 ;
C13851
All words from master 10724 29E4 A 8 UNSIGNED_16 1 ;
C13852
All words to standard device 10723 29E3 A 8 UNSIGNED_16 1 ;
C13853
All words from standard device 10722 29E2 A 8 UNSIGNED_16 1 ;
C13860
Settings 10715 29DB A 4 UNSIGNED_8 1 ;
C13861
Bus status 10714 29DA E 1 UNSIGNED_16 1 ;
C13862
Bus counter 10713 29D9 A 4 UNSIGNED_16 1 ;
C13863
Baud rate 10712 29D8 E 1 UNSIGNED_8 1 ;
C13864
Active station address 10711 29D7 E 1 UNSIGNED_8 1 ;
C13865
Display: Most recent PRM data 10710 29D6 E 1 OCTET_STRING ;
C13866
Display: Most recent CFG data 10709 29D5 E 1 OCTET_STRING ;
C13867
Display: Most recent diagnostic data 10708 29D4 E 1 OCTET_STRING ;
C13880
Reaction on communication failure 10695 29C7 A 1 UNSIGNED_8 1 ;;
C13881
Monitoring time: Data exchange 10694 29C6 E 1 UNSIGNED_16 1 ;;
C13882
Monitoring time: Watchdog 10693 29C5 A 2 UNSIGNED_32 1 ;
C13885
Delete process data 10690 29C2 E 1 UNSIGNED_8 1 ;;
C13886
Set ext. diagnostic bit in case of 10689 29C1 E 1 BITFIELD_8 ;;
C13887
Suppress signalling diag. mess. upon 10688 29C0 E 1 BITFIELD_8 ;;
C13899
Station address 10676 29B4 E 1 UNSIGNED_8 1 ;;
C13900
Firmware product type 10675 29B3 E 1 VISIBLE_STRING ;
C13901
Firmware compilation date 10674 29B2 E 1 VISIBLE_STRING ;
C13902
Firmware version 10673 29B1 E 1 VISIBLE_STRING ;
C13920
Display: DIP switch setting 10655 299F E 1 UNSIGNED_8 1 ;
C13950
Module internal communication
status
10625 2981 E 1 UNSIGNED_8 1 ;
