Preface and general information
How to use this System Manual
1.1.1 Information provided by the System Manual
1−3
l
EDSVS9332P−EXT DE 2.0
1.1 How to use this System Manual
1.1.1 Information provided by the System Manual
Target group
This System Manual addresses to all persons who dimension, install, commission, and set 9300
servo position controllers.
Together with the System Manual, document no. EDSVS9332P, and the catalog, it forms the basis
for project planning for the manufacturer of plants and machinery.
Contents
The System Manual (supplement) completes the System Manual, document no. EDSVS9332P:
l The features and functions are described in detail.
l It describes additional possible applications in detail.
l The parameterisation for typical applications is pointed up by the use of examples.
l In case of doubt the Mounting Instructions supplied with the 9300 servo position controller are
always valid.
Contents of System Manual Contents of System Manual (supplement)
1 Preface 1 Preface
2 Safety −
3 Technical data −
4 Mounting the standard device −
5 Wiring the standard device −
6 Commissioning −
7 Parameter setting −
8
Configuration
2
Configuration
8.1 Monitoring 2.1 Configuration with Global Drive Control
8.2 Monitoring functions 2.2 Basic configurations
8.3 Code table 2.3 Modes of operation
8.4 Selection lists 2.4 Change of the terminal assignment
8.5 Table of attributes
− 3 Function library
− 4 Application examples
9 Troubleshooting and fault elimination −
10 DC−bus operation −
11 Safe standstill −
12 Accessories −
13 Appendix 5 Appendix
