206-4281

LG Setup Wizard (Cont.)

LG Setup Wizard

Welcome to LG’s Setup Wizard

This wizard features two different setup options:

• The EXPRESS SCRIPT provides streamlined conguration of this TV for Free-To-

Guest (FTG) via CPU operation (including pillow speaker setup). The Express Script

also provides the option to congure the TV for Pro:Centric operation.

• The EZ-MANAGER provides automated or manual options for conguring

Pro:Centric operation. The EZ-Manager also provides the option to congure the TV

using a USB memory device.

Exit

EZ-Manager

Express Script

(FTG operation supports physical or logical tuning of clear and encrypted content channels.)

Select the desired option, or exit this setup wizard to perform a custom setup.

From the Welcome screen, you have the following options:

• To proceed with the EZ-Manager Wizard, use the arrow keys on the Installer Remote to select/

highlight EZ-Manager, and then press OK. Then, continue to the “EZ-Manager Wizard” section

on pages 14 to 19.

• To proceed with the Express Script, use the arrow keys on the Installer Remote to select/highlight

Express Script, and then press OK. Then, continue to the “Express Script” section on pages 20

to 25.

• To exit the Setup Wizard, use the arrow keys on the Installer Remote to select/highlight Exit, and

then press OK. In the conrmation pop-up window, select OK, and then press OK once more on

the Installer Remote.

Note: Both the EZ-Manager Wizard and the Express Script enable you to congure Pro:Centric

settings on this TV, even if you do not intend to congure any of the additional settings available.

After you congure the Pro:Centric settings, you will have the option to exit without completing the

remainder of the EZ-Manager Wizard or Express Script (as applicable), if desired.

Note: If you exit the Setup Wizard from this Welcome screen, no conguration will be performed

and all Installer Menu items will retain their default values, including Installer Menu item 119

DATA CHANNEL. The default DATA CHANNEL setting (255) means that the Pro:Centric remote

management feature on this TV will be activated if a Pro:Centric server is installed and the Data

Channel value is set during a Data Channel Auto Search (see item 119 description on page 39

for additional information). If you actually would like to disable the Pro:Centric feature, both the

EZ-Manager Wizard and the Express Script provide an option to do so.

Questions and Answers:

Need help?

Do you have a question about the LG 22LX570M and is the answer not in the manual?

LG 22LX570M Specifications

General

Panel life	- h
Pixel pitch	- mm
Response time	9 ms
Display diagonal	21.6 \
Display brightness	- cd/m²
Display resolution	1366 x 768 pixels
Display technology	LED
Contrast ratio (dynamic)	1000000:1
Contrast ratio (typical)	1000:1
Display number of colors	-
USB version	2.0
USB 2.0 ports quantity	1
Product color	Silver
Product design	Digital signage flat panel
Panel mounting interface	75 x 75 mm
RMS rated power	5 W
Power consumption (standby)	0.5 W
Power consumption (typical)	20 W
Sustainability certificates	RoHS, ENERGY STAR
Certification	UL, FCC, RoHS, cUL, NOM, Energy Star 7.0
Picture mode	Vivid, Standard, Eco, Cinema, Sport, Game
