LG 22LX570M User Manual

30
206-4281
As part of the Installer Menu header (in all modes), two 3-character acronyms are displayed to indicate
the TV’s current conguration mode. The table below lists all possible mode identiers for these TV
models.
Acronym Description
CPU-CTV Pass-through Mode with channel lineup in CPU
CPU-FTG FTG Mode via CPU
CPU-P:C Application Tuning Mode via CPU
EBL-FTG FTG Mode via EBL
EBL-LNT SONIFI PPV Mode
MPI-EXT External MPI Control
PTC-CTV Pass-through Mode with channel lineup in PTC
Using the Installer Menu
Refer to the table starting on the next page for an overview of the available Installer Menu items,
including their item numbers, functions, value ranges, and default values.
Installer Menu items not relevant to these TV models are not present in the Installer Menu; therefore,
some numbers are missing. For example, item 006 will not appear. In addition, items that are
dependent on other Installer Menu item settings will not be initially accessible. For example, item 046
STRT AUX SRCE will not display in the Installer Menu unless item 004 STRT CHANNEL is set to 0.
See Installer Menu detailed descriptions for further information.
Navigation within the Installer Menu
Use the Up/Down arrow keys on the Installer Remote to sequence through the available menu items,
or access an item directly by keying in the item number and then pressing MENU. For example, to
access the SLEEP TIMER option, which is item 015, press 0-1-5 + MENU.
Changing Installer Menu Settings
To change an Installer Menu item value, use the Left/Right arrow keys on the Installer Remote, or
enter a valid value directly. To save the new setting, press OK, or use the Up/Down arrow keys to
navigate to a new Installer Menu item if you have additional items to edit. Note that invalid values will
not be saved.
Exiting the Installer Menu and Activating Settings
After you have adjusted all required Installer Menu item settings, press OK once on the Installer
Remote to save your changes; then, press OK again to exit the Installer Menu. Any changes you
make will be stored in non-volatile memory.
Note: Each time you exit the Installer Menu in Pass-through Mode, all V-Chip (Parental Control)
settings in the TV are reset to their default values; that is, the Lock System, if previously enabled
from the Lock setup menu, will now be disabled, and the individual Parental Control settings will be
restored to default values.
Installer Menu (Cont.)
Caution: Installer Menu settings may affect options available
from the TV setup menus or the Function Menu.

LG 22LX570M Specifications

General

Panel life	- h
Pixel pitch	- mm
Response time	9 ms
Display diagonal	21.6 \
Display brightness	- cd/m²
Display resolution	1366 x 768 pixels
Display technology	LED
Contrast ratio (dynamic)	1000000:1
Contrast ratio (typical)	1000:1
Display number of colors	-
USB version	2.0
USB 2.0 ports quantity	1
Product color	Silver
Product design	Digital signage flat panel
Panel mounting interface	75 x 75 mm
RMS rated power	5 W
Power consumption (standby)	0.5 W
Power consumption (typical)	20 W
Sustainability certificates	RoHS, ENERGY STAR
Certification	UL, FCC, RoHS, cUL, NOM, Energy Star 7.0
Picture mode	Vivid, Standard, Eco, Cinema, Sport, Game

Weight and Dimensions

Depth	50.8 mm
Width	508 mm
Height	304.8 mm
Weight	2720.5 g
