Reference: LX570M Hospital Operations
Hospital Features
The following table identies when and how the LX570M hospital features are supported in three different
TV congurations. As indicated in the introduction to this document, LG commercial TV functionality is based
on “ownership” of the Channel Map. For the purposes of this table, “CPU” indicates that the TV is in Pass-
through Mode with the Channel Map in the CPU (i.e., auto-tuned/edited channel lineup) and “PTC” indicates
that the TV is in Pass-through Mode with the Channel Map in the PTC (PTC-CTV Mode).
CPU
PTC FTG/PPV Mode
Hospital Mode State Disabled Enabled Disabled Enabled Disabled Enabled
Installer Menu Item
IR Banks Enable 012 X
Scan Mode 013 X X X* X*
Start Channel in Scan Mode 014 X X X* X*
Feature Level 020
Bed 1/Bed 2 020 X X X
Multi-code IR 020 X X X X X X
Speaker 020 X X X
Function Preview 025 X X
Hospital Mode 027
Bed 1/Bed 2 027 X X X
Pillow Speaker Voltage 027 (b) X (b) X (b) X
Speaker 027 X X X
Quick Shutoff 077 (c) (c) (c) (c) (c) (c)
Channel Banks
Number of Banks Enabled 1 4 1 4*
Channel Preview/Banks Setup Menu X X
Blanked Channel X X X X
Inactive TV X X*
SAP Key (special use in Channel
Preview/Banks Setup Menu)
X X*
Aux Input Sources
Input List Menu X X X X
Aux in Channel Lineup X X (d) X*/(d)
TV Setup Menus
Audio (TV Speaker) (e) (e) (e) (e)
Option (Power Indicator) X X X X
* Applicable for FTG Mode via CPU only.
X = feature supported
a) Turn ON function only. Always goes to channel 2-0.
b) Defaults to Zenith pillow speaker code/(+12v) supply voltage.
c) Quick Shutoff feature only functions when Scan Mode is enabled and if you are using an analog pillow speaker.
d) Dependent upon installer-dened FTG/PPV Channel Map.
e) Audio Menu is only accessible when the speaker selected is TV Only or both TV & Pillow.
