46
206-4281
(Continued from previous page)
5. Press MENU on the Installer Remote to display the TV setup menus
(TV is in Pass-through Mode) or the Function Menu (TV is already in
FTG Mode).
6. Use the arrow navigation keys to select/highlight either the Option
menu icon from the TV setup menus or the Lock menu icon from the
Function Menu. Then, press the number “7” key a total of seven times
to display the TV Manager / USB Download Menu.
7. With the TV Manager / USB Download Menu on display, use the Up/
Down arrow keys to select Import Clone File, and then press OK.
8. In the Import Clone File window, use the Up/Down arrow keys to select
the “.tlx” le you want to import.
Note: Filenames of exported Clone les are comprised of the TV
model and a ve-digit number, for example, xxLX570M-UA00001.TLX .
9. If the Clone/Conguration (.tlx) le includes an FTG Channel Map,
select the desired Channel Tuning / Channel Banner Display option at
the right side of the Import Clone File window:
• Press the green button on the Installer Remote to select
Logical tuning, or
• Press the yellow button on the Installer Remote to select
Physical tuning.
A checkmark will appear at the left of the selected option. Logical
tuning is selected by default.
Note: If the “.tlx” le does not include an FTG Channel Map, the
message, “No Channel Map in TLX le,” will be displayed at the right
of the screen.
Cloning Procedures (Cont.)
Importing TLX File... 50 %
Do not remove the USB from the port! Do not unplug!
xxLX570M-UA00001.tlx
Import Clone File
xxLX570M-UA00001.TLX
Channel Tuning /
Channel Banner Display
Logical
Physical
TV Manager
USB
Diagnostics
Ez Download
Logo Image Download
Update TV Software
Update PTC Software
Import Clone File
Note: TV Manager / Diagnostics
is for service use only.
10. Press OK on the Installer Remote when you are ready to continue.
Import progress will be shown in a new window. Do NOT remove the
USB device while importing is in progress. When the import process
is complete, an “Updating Complete” window will briey be displayed, and
then, the TV will reboot.
11. Remove the USB memory device from the Target TV, and verify that the
appropriate configuration is now resident on the Target TV.
Note: If the Target TV was previously in Pass-through Mode and the Clone/Conguration
(.tlx) le that was imported contained an FTG Channel Map, the Target TV CPU is now
in FTG Mode. Upon restart, the TV tunes according to the Start Channel setting in the
Installer Menu. If a Start Channel is specied, the TV will tune to that channel, though, in
the case of FTG Mode via CPU conguration, a channel banner will only be displayed if the
Start Channel is included in the FTG Channel Map (depending on your selection in step 9,
the channel banner will display either the Start Channel’s logical channel number or
physical RF channel number). Otherwise, the TV will either return to the last channel
tuned (TV in Pass-through Mode) or tune to the rst channel in the FTG Channel Map (TV
in FTG Mode via CPU). If the latter, remember that the channels in the FTG Channel Map
are always arranged in logical order, regardless of your selection in step 9.
Previous
OK
CC
OK
Previous
CC

LG 22LX570M Specifications

General

Panel life	- h
Pixel pitch	- mm
Response time	9 ms
Display diagonal	21.6 \
Display brightness	- cd/m²
Display resolution	1366 x 768 pixels
Display technology	LED
Contrast ratio (dynamic)	1000000:1
Contrast ratio (typical)	1000:1
Display number of colors	-
USB version	2.0
USB 2.0 ports quantity	1
Product color	Silver
Product design	Digital signage flat panel
Panel mounting interface	75 x 75 mm
RMS rated power	5 W
Power consumption (standby)	0.5 W
Power consumption (typical)	20 W
Sustainability certificates	RoHS, ENERGY STAR
Certification	UL, FCC, RoHS, cUL, NOM, Energy Star 7.0
Picture mode	Vivid, Standard, Eco, Cinema, Sport, Game

Weight and Dimensions

Depth	50.8 mm
Width	508 mm
Height	304.8 mm
Weight	2720.5 g
