Owner’s & Installation Manual 47
46 New Wide Wired Remote Controller
Owner's Instructions
Function Setting - Change Temp
Press the button until the
icons flashes.
1
Press button to change.
❈ Converting temp value : 1~7
2
Press button to complete
and active the setting process.
3
Pressing the button will exit
the settings mode. If is not
pressed, the remote controller
will automatically exit setup mode
after 25 seconds with no input.
If the set button is not pressed,
the changes will not take effect.
4
Change temperature function can change a delta temperature of Auto change over function. The
change temperature value consist certain gap between cooling and heating change over points.
Owner's Instructions
Press the button until the
icons flashes.
1
Press button to select active vane :
1 / 2 / 3 / 4 / All / Standard
Select Vane number using buttons.
❈ Vane number : No. 1, 2., 3, 4, all, or
standard
- Selected vane is in operation.
- Please verify the operating vane.
- To set the angle of all the vanes,
select 'all'.
- To set as the factory default settings,
select 'standard'.
2
Select wind angle using button, and
press button.
- The boundary of wind angle settings can
be changed to 5 levels or 6 levels
according to the product.
- When selecting 'standard' for Vane
number, the wind angle does not move.
3
Set the angles for the remaining vanes
by following the same steps.
4
Pressing the button will exit
the settings mode. If is not
pressed, the remote controller
will automatically exit setup mode after
25 seconds with no input. If the set button
is not pressed, the changes will not take
effect.
5
Press button to complete and
activate the setting process.
(Airflow direction function will be
released whenever setting vane angle)
6
Press button to exit or
system will automatically release
without any input after 25
seconds.
7
This function is to adjust angle at which airflow is blown out.
Function setting - Vane Angle Control
