Network Settings
23
5.3.3 Display/Modify SNMPv1/v2c Trap Communities
View or modify devices that are configured to receive notifications from the Web card, identified by IP
address or hostname, trap listen port and community string.
Up to 20 devices may be configured to receive traps.
Each device is identified by:
• Entry Number - use the entry number (1-20) to edit or delete an entry
• IP address or hostname - the address or name of the device to receive traps (MultiLink server,
Nform server, Network Management System)
• Port - the Trap Listen Port where traps will be sent; use 162 if the host computer uses standard
ports (161/162)
• Community string - the community string used by the IP host for this Entry Number
(case-sensitive, up to 32 characters)
To make changes:
Add a device (see example at right to enter all parameters in one line):
• Enter a to add an entry, then press Enter.
• Enter the IP address or hostname of the device to be added, then press
Enter.
• Enter the port number (default is 162), then press Enter.
• Enter the community string, then press Enter.
Example
a 10.0.0.5 162 public1
(then press Enter)
Edit a device (see example at right to enter all parameters in one line):
• Enter e to edit an entry, then press Enter.
• Type the Entry Number, then press Enter.
• Enter the new IP address or hostname, then press Enter.
• Enter the port number (default is 162), then press Enter.
• Enter the new community string, then press Enter.
Example
e 2 10.0.0.7 162 public2
(then press Enter)
Delete a device (see example at right to enter parameters in one line):
• Enter d, then press Enter. No confirmation message will appear.
• Type the Entry Number, then press Enter.
Example
d2
(then press Enter)
Trap Communities
-----------------
1:
10.0.0.5 162 public1
2:
10.0.0.6 162 public1
<a>dd <d>elete <e>dit
Complex lines allow
ed. e.g. <a
198.1.1.1
162 public>
?>
Entry
#
IP
address
Port to
receive traps
Community
string
Codes for
editing
EXAMPLE
