4 Product Description
4.1 Mattress
The CliniCare 100 HF system is designed for use in all healthcare facilities, hospitals, nursing homes and community care as an aid
to the prevention and treatment of skin injuries related to pressure damage.
4.1.1 CliniCare 100 HF
CliniCare 100 HF is a hybrid foam including cell system. Cells are connected into two groups for pressure distribution. Air tubes
inside the mattress are separate for these two groups. Cells also includes pressure valve to gain pressure from atmosphere when
needed. The system can be connected to compressor thanks to outer valves. The system works as a separate mattress or in
connection with compressor. Separate mattress redistributes the pressure according to patient’s position and movement. When the
compressor is connected the mattress provides alternating therapy. In case of MCM version compressor also delivers air for MCM
feature in mattress. Inside the mattress there is foam with di󰀨erent densities. On the top of mattress there is visco foam. Inside the
cells there is PU foam. The pressure delivered by compressor can be adjusted by controller.
Fig. CliniCare 100 HF mattress
1 Top cover
2 Comfort layer
3 Mattress Serial Label Holder
4 Mattress Serial Label Lamination
5 Tubing Harness MCM (only version with MCM)
6 Foam layer
7 Cell Sleeve
8 Reactive Cell
9 Tubing Harness A
10 Check Valve
11 Tubing Harness B
12 Base Cover
13 Air Connection
7
8
9
10
11
13
12
1
2
3
4
5
6
