LINET CliniCare 100 HF User Manual

D9U003VC0-0101_05 15
Top foam:
■ height: 5 cm
■ material: visco foam
Middle section:
■ 10 self-adjusting air cells absorb and displace patient weight
■ when used with SCU, air cells alternate in pressure, and micro climate management is optional
■ material:PU
Cover:
■ Top
□ 4 way stretch with 360 degree zip
□ waterproof / high Moisture Vapour Permeability
■ Base
□ high durability / non stretch / waterproof
□ 2 strong mattress Transport Handles on each side of the base
Fig. SCU for CliniCare 100 HF with MCM mode Fig. SCU for CliniCare 100 HF without MCM mode
4.2 SCU (System Control Unit)
The SCU in ates and de ates the air mattress. It is connected to the air mattress with a custom-designed air connector. The ana-
logue electro-mechanical controlled SCU maintains the set pressure regardless of the patient’s weight distribution or position. The
SCU is equipped with visual indicators for power failure or mattress low air pressure that may be caused by air pipe disconnection
or other faults (see chapter “System Faults”).
