LINET CliniCare 100 HF User Manual

D9U003VC0-0101_05 17
5.2 Electrical Specications
Parameter Value
Supply nominal voltage 220-240 VAC, 50/60 Hz
Maximum input power 15VA
Ingress Protection (SCU) IP3X
Power plug NEMA Type 1-15P polarized
Fuses (SCU) 2x (T 1A L) anti-surge fuse
(250 V, type 5x20mm)
Electrical safety class Class II with applied parts type B
Electrical safety In conformity with IEC 60601-1
Electromagnetic compatibility IEC 60601-1-2
Fire Resistance (mattress cover) BS 7175 ignition sources 0, 1 and 5
CAUTION!
Height value of the edge of not loaded inated mattress is 18 cm and height value in the middle of the mattress
is 22,5 cm. This fact does not increase the risk of patient´s falling down over the siderails. Decisive value for
choice of the safe mattress in relation to the siderails is 18 cm.
Parameter Value
External mattress dimensions (length x width) 200 x 100
Mattress height (inated) 22 cm
Mattress height (deated) 18 cm
External dimensions of SCU (length x width x height) 30 x 12 x 22 cm
Weight
■ CliniCare 100 HF mattress
■ CliniCare 100 HF System Control Unit (SCU)
17 kg
2,5 kg
Cycle
■ Mattress (inated) 2 cells technology, 12 minutes
Environmental conditions (Use conditions)
■ Ambient Temperature
■ Relative Humidity
■ Atmospheric Pressure
10 °C – 40 °C
30% – 75%
795 – 1060 hPa
Environmental conditions (Storage and Transport Conditions)
■ Ambient Temperature
■ Relative Humidity
■ Atmospheric Pressure
-20 °C – 50 °C
20% – 90%
795 – 1060 hPa
Maximal load 180 kg
Sound Pressure Level 35 dBA
100 CM WIDE VERSION
