Loewe Connect ID 55 DR+ User Manual

Connect ID 40-55
User guide
11
1
USB - USB connection
2
RS-232C - Serial interface
3
PC IN - Mini AV socket
(1
4
HDMI 1 - HDMI input 1 (with HDMI ARC support)
5
HDMI 2 - HDMI input 2
6
HDMI 3 - HDMI input 3
7
ANT TV - Antenna/cable analogue/digital
8
ANT SAT - Satellite antenna (Sat tuner)
9
SPDIF OUT - Digital audio output
10
LAN - Network connection
(2
11
CI-COMMON INTERFACE - Common Interface (CI slot)
12
- Headphone connection
13
HDMI 4 - HDMI input 4
14
AV - Mini AV socket
(1
15
USB - USB connection
16
USB - USB connection
17
Socket for Kensington lock
18
AC IN - Mains connection

Connections rear side of the device
(1
Adaptor set is available as an accessory (see chapter Accessories).
(2
Only use a LAN cable without a cap over the locking mechanism (see image
A
). LAN cables with caps may cause problems when the cable is being disconnected.
K
1 2
11
9
10
12
13
15
4 5 3
8
6
7
14
17
16
18
A
