3 -11
▶ When driving on the road, disengage the 4WD. If not, it may cause damage of
drive line and serious accident. After working, before coming out from the field,
select 2WD.
▶ When driving the tractor at high speed while the 4WD is engaged, sharp steering
may cause a accident.
Caution
(5) 4WD lever
z Stop the tractor completely before operating the
4WD lever.
z Push the lever forward to drive front wheels and
pull the lever to disengage the 4WD.
z Four wheel drive (4WD) is effective for the
followings.
-when traction is needed in plow ground.
-when working on slippery ground.
-when working with tiller on hard ground.
-When crossing a ridge
4WD lever
(6) Differential lock pedal
z If the tractor cannot go forward as one side rear
wheels are slipping, press the differential lock
pedal.
z Differential lock is effective for working on slippery
ground and working with a plough.
z If engaged, both rear wheels will rotate at equal
speed. So, It disturbs steering operation and you
cannot turn.
▶ Do not turn the tractor while the differential lock is engaged.
▶ Do not use the differential lock while driving on the road.
▶ Stop or slow the tractor before engaging the differential lock.
Warning
Differential lock
pedal
HST type
z Take your foot off the pedal to release the differential lock. If the traction is equalized, the differential
lock is released automatically.
z If the differential lock does not disengaged, depress one side brake
pedal slightly for a second, and then the other.
