5 -36
▶ Be sure to stop the engine before loosening the oil filter.
▶ If the filter or oil is very hot, it may cause serious burns. After cooling down the
tractor sufficiently, replace the filters
.
Warning
Hydraulic
oil filter
Open
Close
▶Do not throw the exhausted waste oil to any place. This may pollute the soil and
water seriously and also is prohibited legally. If violating, you would be responsible
for that by civil or criminal case. The waste oil must be disposed according to the
environment laws.
Caution
(2) Replacing Hydraulic Oil Filter
① Hydraulic oil filter (Main)
Stop the tractor on a level surface and apply
parking brake and lower implements. Stop the
engine and cool down the tractor sufficiently.
This filter is attached under the right-hand floor.
Carefully clean around the filter and set a clean
container under the filter.
Coat clean hydraulic oil on the packing of new
filter and check the packing is placed well in the
groove.
Turn the oil filter counter-clockwise to remove it
with a filter wrench.
Turn the new filter clockwise to assemble it until the packing makes contact with the mounting
surface. Tighten the filter 3/4 to 1 turn more after the contact.
Run the engine at low idle rpm and check any leakage.
Check the oil level. If necessary, add new oil. For oil specification, see chapter 5-3, “Lubricants and
Capacity” or the last page in this manual.
To Next Page
