LS tractor MT345E User Manual

5 -42
5-11. Every 600 hour check
(2) Changing Transmission oil
 Stop tractor on a level surface and apply parking
brake. Run engine for several minutes to warm
oil and lower implements and stop the engine.
 Clean around the oil filling inlet and drain plugs.
 Set a clean container under drain plugs and
remove them under the transmission and drain
the oil completely.
 Clean metal sludge stuck to the drain plugs and
tighten the drain plugs again with copper washer.
 Add new oil until the oil level is between MIN and
MAX mark of the oil gauge.
 For oil specification, see chapter 5-3, “Lubricants
and Capacity” or the last page in this manual.
Drain plugs
Oil filling inlet (2.0L)
& Air breather
Oil filling inlet (3.5L)
& Oil gauge
(1) Changing Front axle oil
 Stop the tractor on a level surface and apply
parking brake. Clean around oil filling inlet and
drain plugs.
 Remove the left/right drain plugs and oil filling
inlets to drain the oil completely.
 Tighten the drain plugs again to the original
position.
 Add new oil into the oil filling inlets.
- kingpin case : 3.5L(LH), 2.0L(RH)
- gear case : 1.7L (each side)
 After about 5 ~10 minutes later, re-check the oil
level and tighten the oil filling inlet plugs.
 For oil specification, see chapter 5-3, “Lubricants
and Capacity” or the last page in this manual.
Oil filling inlets
(1.7L each side)
<Oil gauge >
Max.
Min.
Oil filling inlet
& Oil gauge
Drain plugs
▶ Contaminated oil may reduce
the durability of transmission
drive lines and it can cause a
failure of the hydraulic system.
Clean around the oil filling inlet
and then pull the oil gauge.
Caution
