Limiting values
Service Data
Dimensions
136
Flywheel and starter motor gear ring
Ø Flywheel: 432,490-432,645 mm
Starter gear ring, inside diameter:
432,000-432,155 mm
Interference: 0,335-0,645 mm
Installation temperature: 200-230_C
m = 65,1 kg (with starter gear)
J = 2,412 kgm
2
Number of teeth: Z = 160, Module 3
Matching gear:
Starter pinion: number of teeth: (Z = 9)
Backlash: 0,6-0,9 mm
ØØ
