SET-UP AND INSTALLATION 18000 OPERATOR MANUAL
4-30
Published 12-05-17, Control # 032-23
FIGURE 4-20
View A
1
2
3
4
11° Mast Angle
4-117
160°
An assist crane must be
used to lower mast to
angles greater than 160°.
View C
View B
6
4
5
Stored
6
4
5
Working
4-116
Item Description
1Live Mast
2 Mast Assist Arms with Cylinders
3 Drum 3 (Whip Line)
4 Live Mast Straps (2 places)
5 Locking Pin with Cotter Pins (2 each)
6 Pin with Cotter Pins (2 each)
7 Load Pin With Keeper Plate (right side)
114°
180°
With MAX-ER
Configuration
Standard Pin
Configuration
View D
7
4-118
4-119
4-120
