Manitowoc Published 12-05-17, Control # 032-23 4-113
18000 OPERATOR MANUAL SET-UP AND INSTALLATION
Raise Jib Strut (continued)
See Figure 4-60 for the following procedure. Circled
numbers in figure match steps in procedure.
13. Lower jib strut until jib straps and links (5, View A) are
directly above equalizer brackets (6) and support
pendants (11, View A) are taut.
14. Connect sling (8, View B) from assist crane or other
lifting equipment to lifting lug on jib strap equalizer (7).
15. Raise equalizers (7, View C) until straps and links (5)
can be connected to equalizer links (9, View D).
16. Pin straps and links (5) to equalizer link (9) using pin
(10). Retain pins with collars, pins, and cotter pins (View
D).
17. Disconnect lifting sling (8) from equalizer (View A).
18. Repeat steps 14–17 for other equalizer.
19. Continue to raise strut slowly (View F) until connection
holes in strut insert and strut butt are aligned.
20. Lower assist crane slightly to close strut joint.
21. Connect strut top (1) to butt (8) using pins (12, View E).
Retain pins with snap pins.
22. Disconnect sling (2) from assist crane from strut top.
23. Remove pin (3) from Hole A and insert in Hole B
(Figure 4-32
, View B).
24. Check that support pendants (13) are inside strap
brackets (14).
25. Stow pendants for operation by inserting strap shipping
pin (15) into strap bracket (14) as shown in View G.
Install Jib Load Line
The Drum 2 load line is used for the lower jib point. This line
has multi-part reeving. The Drum 3 load line is used for the
upper jib point, if equipped.
See Wire Rope Specifications to determine parts of line
required for your job and size load block accordingly. See the
Fixed Jib Capacity Charts for capacity limitations.
Route load lines through proper guide sheaves on boom
butt, mast, boom top, and jib top. See Load Line Reeving in
this section for proper routing and reeving of the load lines.
Connect Electric Cords
Connect electric cords to respective junction boxes and
switches in boom and jib (see Boom Wiring and Limits
Drawing at the end of this section).
Connect all unused electric cords to proper terminating plugs
on junction boxes. Boom will not lower and drums will not
hoist if electric cords are not shorted out.
Install Wind Speed Indicator Assembly
Install wind speed indicator if removed for shipping. Use star
washers to attach mounting bracket to jib top to provide good
a ground (see Wind Speed Assembly drawing at the end of
this section).
Connect electrical cable at base of wind speed mounting
bracket.
Legend for Figure 4-60
Item Description Item Description
1 Jib Strut Top 9 Equalizer Link
2 Jib Strut Butt and/or Strut Insert 10 Connecting Pin w/Collar and Retaining Pins
3 Sling from Assist Crane 11 Jib Straps
4 Adjustable Link 12 Pin w/Snap Pin, 2-1/2 in (64 mm)
5 Jib Straps and Links 13 Support Pendant
6 Strap Support Bracket 14 Strap Bracket
7 Jib Strap Equalizer 15 Pin w/Cotter Pin
8 Lifting Sling 16 Lifting Lug
