INTRODUCTION 18000 OPERATOR MANUAL
1-8
Published 12-05-17, Control # 032-23
50 ft (15,2 m) jib strut with guide sheave, luffing sheaves and links - - - - - - - - - - - - - - 13,285 6 025
47 ft (14,3 m) main strut with luffing sheaves and links - - - - - - - - - - - - - - - - - - - - 9,425 4 275
Luffing wire rope guide - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1,070 485
38 ft 2 in (11,6 m) backstay basic strap (with connector links) (each) - - - - - - - - - - - - - 510 231
10 ft (3,0 m) backstay strap (with connector links) (each) - - - - - - - - - - - - - - - - - - 175 79
20 ft (6,1 m) backstay strap (with connector links) (each) - - - - - - - - - - - - - - - - - - 290 131
40 ft (12,2 m) backstay strap (with connector links) (each) - - - - - - - - - - - - - - - - - - 525 238
40 ft (12,2 m) transition backstay strap (with connector links) (each) - - - - - - - - - - - - - 525 238
10 ft (3,0 m) No. 55 backstay strap (with connector links) (each) - - - - - - - - - - - - - - - 405 183
20 ft (6,1 m) No. 55 backstay strap (with connector links) (each) - - - - - - - - - - - - - - - 675 306
40 ft (12,2 m) No. 55 backstay strap (with connector links) (each) - - - - - - - - - - - - - - 1,220 553
Backstay link (attached to boom butt) (each) - - - - - - - - - - - - - - - - - - - - - - - - 115 52
Luffing jib stop assembly - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1,850 839
Upper point (single sheave) with rollers - - - - - - - - - - - - - - - - - - - - - - - - - - - 1,220 553
FIXED JIB NO. 79A:
20 ft (6,1 m) butt No. 79A - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 10,295 4 669
30 ft (9,1 m) top with double straps, upper (heavy duty) and lower point and wire rope guide - 27,780 12 600
20 ft (6,1 m) insert No. 79 with double straps - - - - - - - - - - - - - - - - - - - - - - - - 7,835 3 553
40 ft (12,2 m) insert No. 79 with double straps - - - - - - - - - - - - - - - - - - - - - - - - 13,180 5 978
28 ft 2-15/16 in. (8,6 m) basic strap (each) - - - - - - - - - - - - - - - - - - - - - - - - - 355 161
20 ft (6,1 m) jib strap with links (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - 290 131
40 ft (12,2 m) jib strap with links (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - 525 238
Equalizing link (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 375 170
10 ft (3,0 m) strap (with connector links) (each) (20 degree offset) - - - - - - - - - - - - - - 355 161
7 ft (2,1 m) strap (with connector links) (each) - - - - - - - - - - - - - - - - - - - - - - - - 345 156
4 ft 9 in (1,4 m) strap with pin (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - 195 88
4 ft 9 in (1,4 m) link with pin (set each) - - - - - - - - - - - - - - - - - - - - - - - - - - - 185 83
6 ft 2 in (1,9 m) strap with pin (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - 265 120
Jib stop assembly (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1,890 857
Jib hinge pins/link assembly (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 340 154
29 ft (8,8 m) strut butt - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5,325 2 415
21 ft (6,4 m) strut top - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4,625 2 097
1 ft 5 in (0,4 m) spreader link with pins - - - - - - - - - - - - - - - - - - - - - - - - - - - 690 312
1 ft 10 in (0,6 m) link with pins (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - 225 102
1 ft 10 in (0,6 m) link (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 135 61
1 ft 7 in (0,5 m) spreader link with pins (each) - - - - - - - - - - - - - - - - - - - - - - - - 535 242
Adjustable link with pins (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 585 265
7 ft 4 in (2,2 m) backstay strap (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - 275 124
30 ft (9,1 m) backstay strap with links (each) - - - - - - - - - - - - - - - - - - - - - - - - 865 392
20 ft (6,1 m) backstay strap with links (each) - - - - - - - - - - - - - - - - - - - - - - - - 610 276
40 ft (12,2 m) backstay strap with links (each) - - - - - - - - - - - - - - - - - - - - - - - - 1,120 508
10 ft (3,0 m) backstay strap with links (each) - - - - - - - - - - - - - - - - - - - - - - - - 355 161
1 ft 11-1/2 in (0,6 m) backstay link, pins (each set) - - - - - - - - - - - - - - - - - - - - - - 115 52
LUFFING JIB NO. 79A:
20 ft (6,1 m) butt No. 79A - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 10,315 4 678
30 ft (9,1 m) top with double straps, upper (heavy duty) and lower point and wire rope guide - 27,835 12 625
20 ft (6,1 m) insert No. 79 with double straps - - - - - - - - - - - - - - - - - - - - - - - - 7,835 3 553
20 ft (6,1 m) insert No. 79 without straps - - - - - - - - - - - - - - - - - - - - - - - - - - 6,700 3 039
40 ft (12,2 m) insert No. 79 with double straps - - - - - - - - - - - - - - - - - - - - - - - - 13,180 5 978
28 ft 2-15/16 in (8,6 m) basic strap (each) - - - - - - - - - - - - - - - - - - - - - - - - - - 355 161
20 ft (6,1 m) jib strap with links (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - 290 131
40 ft (12,2 m) jib strap with links (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - 525 238
Equalizing link (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 375 170
8.63 in (0,2 m) link, pins (each set) - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
85 38
Description
Weight
Pounds Kilograms
