SET-UP AND INSTALLATION 18000 OPERATOR MANUAL
4-122
Published 12-05-17, Control # 032-23
Rope
Clips
P1519
Wire Rope
without Button
Rigging
Line
FIGURE 4-68
A1189
A09310
Pad
Eye
Wire Rope
from Drum
Pad
Eye
Rigging
Rope
Load Block Sheaves
EXAMPLE
Boom Point
Sheaves
Pull Rigging Line
with Winch or
Fork-Lift Truck
Wire
Rope
Wire Rope
with Button
Pad
Eye
Rope End
Connector
OR
No. 1.0 Pad Eye
Item Inch mm
A 3/8 9,65
B 1/4 6,35
C 7/8 22,40
D 13/32 10,40
E 7/8 22,40
F 1/8 3,30
G 1-1/32 26,20
No. 1.5 Pad Eye
Item Inch mm
A 5/8 16,00
B 1/6 6,35
C 1 25,40
D 7/16 11,20
E 1-1/8 28,70
F 5/32 4,05
G 1-5/16 33,30
B
D
F
E
G
C
A
