Manitowoc Grove RT765E-2 User Manual

Grove Published 4-09-2021, Control # 364-11 2-43
RT765E-2 OPERATOR MANUAL SAFETY INFORMATION
2
STABILITY
The RT765E-2 on rubber load charts has a minimum radius
of 9.8 ft (3 m) with a load. Without a load, a radius of 8.2 ft
(2.5 m) is safe for 360° on rubber. A radius of less than 8.2 ft
(2.5 m) must be avoided on rubber because of backward
stability considerations.
ACCESS PLATFORM HAND RAIL
Ensure that the hoist access platform hand rail (1)
(Figure 2-11) and step (2) (Fixed counterweight units only)
are in the travel configuration. Remove pins from hand rail
and rotate it down into the travel position, reinstall pins. Pull
the step locking pin out, slide the step in to the travel position
and release the lock pin.
Use the hoist access platform (1) (Figure 2-12) when
working in the hoist area (Fixed counterweight units only).
OVERLOAD INSPECTION
When the RCL system has acknowledged an overload on
your crane, you must carry out specified inspections on the
crane.
These inspections apply only to overloads up to 50%. For
overloads of 50% or higher, crane operation must be
stopped immediately and Crane Care must be contacted for
corrective action.
NOTE: If your crane is equipped with CraneSTAR, an
overload warning will be posted to the web site for
review by the crane owner.
Overload warnings do NOT indicate real time
events! Warnings could be sent 24 hours (or more)
after the actual event.
7649-20
FIGURE 2-11
1
2
WARNING
Overload Hazard!
To avoid an accident caused by overload damage to
your crane:
• Perform the inspections outlined in this publication
for overloads up to 50%.
• Stop operating the crane and contact Manitowoc
Crane Care immediately for overloads of 50% and
higher.
7649-14
1
FIGURE 2-12
1
