Manitowoc National Crane NBT40-1 Series User Manual

National Crane 3-29-2018 Control # 610-00 6-1
NBT40-1 SERIES OPERATOR MANUAL SET-UP
6
SECTION 6
EQUIPMENT SET-UP
SECTION CONTENTS
Jib Safety Information . . . . . . . . . . . . . . . . . . . . . . 6-1
Jib Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Deployment Procedure . . . . . . . . . . . . . . . . . . . . . 6-2
Stowing Procedure . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Jib Removal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Jib Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Rope Installation-Hoist. . . . . . . . . . . . . . . . . . . . . . 6-6
Synthetic Rope . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Wire Rope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Multi-part Lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Wedge Sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
Terminator Wedge Installation . . . . . . . . . . . . . . . 6-7
Wedge Socket Installation . . . . . . . . . . . . . . . . . . 6-7
Dead-end Rigging . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Hoist Rope Tie Down. . . . . . . . . . . . . . . . . . . . . . . . 6-9
Hoist Rope Tie Down - Boom Mounted Hoist . . . . 6-9
Stow Pegs for hoist rope . . . . . . . . . . . . . . . . . . . 6-11
A2-B Weight Installation and Stowage . . . . . . . . 6-11
Wire Rope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-11
Synthetic Rope . . . . . . . . . . . . . . . . . . . . . . . . . . 6-11
Aerial Lift Platform . . . . . . . . . . . . . . . . . . . . . . . . 6-12
Aerial Lift Platform Installation . . . . . . . . . . . . . . 6-14
Platform Mounting . . . . . . . . . . . . . . . . . . . . . . . . 6-14
Platform Quick Attachment . . . . . . . . . . . . . . . . . 6-15
Platform Mounting and Installation . . . . . . . . . . . 6-17
Platform Operation. . . . . . . . . . . . . . . . . . . . . . . . 6-17
Platform Brake Operation . . . . . . . . . . . . . . . . . . 6-17
Hydraulic Tool Connection - Optional . . . . . . . . . 6-18
Safety Harness . . . . . . . . . . . . . . . . . . . . . . . . . . 6-18
This section contains information on how to perform the
following tasks:
• Erect the jib.
• Stow the jib
• Remove the jib
• Use multi-part reeving.
• Install the hoist cable.
• Install the anti-two-block weight.
• Install a wedge socket.
• Counterweight
• Aerial Platform Installation
JIB SAFETY INFORMATION
1. The anti-two-block (A2B) switch weight and cord must
be attached to the jib when deployed.
2. Operate with jib by radius when main boom is fully
extended. If necessary, increase boom angle to maintain
loaded radius.
When radius is between points listed on capacity chart,
the load shown at the next longer radius shall be used.
3. Operate with jib by boom angle when main boom is not
fully extended. Do not exceed rated jib capacities at any
reduced boom lengths.
When angle is between points listed on capacity chart,
the load shown at next lower boom angle shall be used.
4. Ensure jib is stowed correctly (Figure 6-1):
a. Removal of swing around pins (C1, Figure 6-1),
without proper installation of stow pin A and jib
swing pin B, may allow jib to fall off.
b. Extending boom with jib stowed and failure to
remove swing pins (C1, Figure 6-1), will damage
unit upon extension.
5. Only swing jib into working or stowed position when
boom is horizontal, stow pin (A, Figure 6-1) and jib swing
DANGER
Do not operate outriggers unless they are visible to either
the operator or a designated signal person to avoid
crushing injury.
!
