Manitowoc National Crane NBT40-1 Series User Manual

National Crane 3-29-2018 Control # 610-00 1-1
NBT40-1 SERIES OPERATOR MANUAL INTRODUCTION
1
SECTION 1
INTRODUCTION
SECTION CONTENTS
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Supplemental Information . . . . . . . . . . . . . . . . . . . 1-1
New Owner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Basic Nomenclature. . . . . . . . . . . . . . . . . . . . . . . . 1-1
GENERAL
This manual has been compiled to assist you in properly
operating and maintaining your Model NBT40-1 SERIES
National Crane (Figure 1-1). The NBT40-1 series includes
crane models NBT36-1, NBT40-1and NBT45-1.
Before placing the equipment in service, all operators and
persons working around the equipment must thoroughly
read and understand the contents of this manual pertaining
to Safety, Operation and Maintenance. Before moving a
vehicle equipped with the crane, information relating to
transporting the vehicle must be read and observed.
This manual must be retained with the machine for use by
subsequent operating personnel.
Information in this manual does not replace federal, state or
local regulations, safety codes or insurance requirements.
For detailed information concerning the operation and
maintenance of the RCL system installed on the equipment,
see the manufacturer’s manual supplied with the equipment.
Manufacturers of rated capacity limiters may refer to them in
their manuals as a load moment indicator (LMI), a hydraulic
capacity alert system (HCAS), National Crane refers to these
systems as a rated capacity limiter (RCL) throughout its
Operator and Service Manuals.)
The NBT40-1 SERIES has been designed for maximum
performance with minimum maintenance. With proper care,
years of trouble-free service can be expected.
National Crane and our Distributor Network wants to ensure
your satisfaction with our products and customer support.
Your local distributor is the best equipped and most
knowledgeable to assist you for parts, service, and warranty
issues. They have the facilities, parts, factory trained
personnel, and the information to assist you in a timely
manner. We request that you first contact them for
assistance. If you feel you need factory assistance, please
ask the distributor’s service management to coordinate the
contact on your behalf.
Supplemental Information
Supplemental Information regarding Safety & Operation,
Specifications, Service & Maintenance, Installation, and
parts for options such as remote controls, augers, varying
control configurations, platforms, grapples, etc. are included
in separate manuals. Most optional content is being added to
this standard manual such as the platform and remotes. The
RCL and optional the hydraulic pressure intensifier are
included as separate manuals.
Whenever a question arises regarding your National Crane
product or this publication, please consult your National
Crane distributor for the latest information. Your National
Crane distributor is equipped with the proper tools,
necessary parts, and trained personnel to properly maintain
and service your equipment.
A Safety Compact Disc or a USB flashdrive which includes
sections on Operation, Service and a Safety Video for
National Crane operators and owners is supplied when the
equipment is purchased new. Additional copies are available
from your local distributor.
New Owner
If you are the new owner of a National crane, please register
it with Manitowoc Crane Care so we have the ability to
contact you if the need arises. Go to:
https://
www.manitowoccranes.c om/en/service s/crane-care/
service-and-tech-support/ Change-of-Ownership-Form
Basic Nomenclature
The nomenclature used to describe parts of a National Crane
are described in Figure 1-2. This nomenclature is used
throughout this manual.
