Metso Valvcon ADC Series User Manual

17. SPECIFICATIONS & TECHNICAL
INFORMATION
Table 1
Torque
Output
Duty
Cycle
at/below
40°C/104°F
12VDC 24VDC 24VAC 115VAC 230VAC
Cycle
Time
Current
Draw
Cycle
Time
Current
Draw
Cycle
Time
Current
Draw
Cycle
Time
Current
Draw
Cycle
Time
Current
Draw
(sec/90°) (Amps) (sec/90°) (Amps) (sec/90°) (Amps) (sec/90°) (Amps) (sec/90°) (Amps)
150 lb-in;
12 lb-ft; 17 Nm
100% 11 2.2 13 1.2 8 1.8 9 0.4 9 0.4
300 lb-in;
25 lb-ft; 34 Nm
100% 17 2.5 13 1.4 12 2.1 13 0.5 13 0.4
600 lb-in;
50 lb-ft; 68 Nm
100% 17 2.8 13 1.7 13 2.5 14 0.6 14 0.5
1000 lb-in;
83 lb-ft; 113 Nm
100% 21 4 14 2.4 15 3.5 15 0.9 15 0.6
1500 lb-in;
125 lb-ft; 169 Nm
100% 40 4 24 2.4 27 3.5 29 0.9 29 0.6
2000 lb-in;
167 lb-ft; 226 Nm
100% 40 4.3 33 2.4 28 3.5 29 0.9 29 0.6
2500 lb-in;
208 lb-ft; 282 Nm
100% 55 3.3 40 2 38 3.1 39 0.8 39 0.6
3000 lb-in;
250 lb-ft; 339 Nm
100% 60 3.7 42 2.2 40 3.5 42 0.8 43 0.6
Table 2 Specifications
Temperature Range -40°F to 130°F (-40°C to 55°C)
Conduit Connections (2) 3/4” NPT all sizes (3/4” to 1/2” reducing bushings included)
Output
150 to 600 in-lbs: ISO 5211 F05 and F07 bolt circles, 3/4” female square standard; see “Dimensions” section
and “How to Order” table for additional output options.
1000 to 3000 in-lbs: ISO 5211 F07 and F10 bolt circles, 1” female square standard; see “Dimensions”
section and “How to Order” table for additional output options.
Voltage
12 VDC: 10.8 to 13.2 VAC
24 VDC: 21.6 to 26.4 VDC
24 VAC: 21.6 to 26.4 VAC, 60 Hz or 50 Hz
115 VAC: 103.5 to 126.5 VAC, 60 Hz or 50 Hz
230 VAC: 207 to 253 VAC, 60 Hz or 50 Hz
Limit Switches (2) Single pole, double throw switches rated for 11A 1/2HP 250VAC CSA certied.
Motor Brushless DC motor with Class B or better insulation; sub-fractional horsepower
Lubrication Permanently lubricated gear train and bearings
Gear Train Hardened steel, machine cut spur gears
Approximate Weight
17 lbs for sizes up to 600 in•lb (ADC models)
31 lbs for sizes 1000 in•lb and above (LADC models)
Enclosure
Die cast aluminum; with a baked-on, super durable polyester powder coat nish
IMO 6/18
20 IMO-I4900 EN

Metso Valvcon ADC Series Specifications

General
