CHAPTER 10: MYA-MINA/LINA MOUNTING YOKE
52
MYA-MINA/LINA LOAD RATINGS
An array of up to three LINA loudspeakers can be flown with the MYA-MINA mounting yoke at a 5:1 safety factor. When fly-
ing any number of LINAs with the yoke, the yoke must be secured to the mounting surface with the 1/2-inch center hole.
CAUTION: When mounting the MYA-MINA/LINA on a pole, make sure the pole and pole-mount adapter have
been rated to support the full weight of the yoke and two loudspeakers. Observe all safety precautions speci-
fied by the pole and pole-mount adapter manufacturer.
Table 9: MYA-MINA/LINA Load Ratings
Mounting Point Safety
Factor
Number of Flown LINAs MYA-MINA Yoke Mounting Plate
0.5 in center hole 5:1 Three LINAs (129 lb, 58.51 kg)
Four 0.25 in
corner holes
NA Not rated for flown applications; these
holes should only be used to attach the
yoke to a pole-mount adapter; a maximum
of two LINAs can be pole-mounted.
Not rated for flown applications
