CHAPTER 14: MCF-750 CASTER FRAME
76
DIMENSIONS: MCF-750 CASTER FRAME WITH RIGGING
MCF-750 Caster Frame with Rigging Weight: 34 lbs (15.4 kg)
Figure 68: MCF-750 Caster Frame (for cabinets with rigging) Dimensions
24.91 in
[633 mm]
24.16 in
[614 mm]
24.16 in
[614 mm]
17.14 in
[435 mm]
7.50 in
[190.5 mm]
5.85 in
[149 mm]
17.70 in
[450 mm]
