Midea
V6R
Series Service Manual
Table 5-2.5: System check
Parameters displayed on DSP2
Standby (ODU address + IDU Qty.)/frequency/particular state
Master unit: 0; slave units: 1, 2
Displayed on master unit PCB only
Number of indoor units as set on PCB
Displayed on master unit PCB only
Total capacity of outdoor unit
Only available for master unit, displayed on slave
units has no sense
Single module compressor frequency
Displayed on master unit PCB only
System compressor frequency
Actual value = value displayed × 10
0: off; 2: cooling; 3: heating; 4: main heating; 5:
main cooling.
Indoor heat exchanger pipe (T2) temperature (°C)
Actual value = value displayed
Indoor heat exchanger pipe (T2B) temperature (°C)
Actual value = value displayed
Main heat exchanger pipe (T3) temperature (°C)
Actual value = value displayed
Outdoor ambient (T4) temperature (°C)
Actual value = value displayed
Outdoor liquid pipe (T5) temperature (°C)
Actual value = value displayed
Plate heat exchanger cooling refrigerant inlet (T6A) temperature (°C)
Actual value = value displayed
Plate heat exchanger cooling refrigerant outlet (T6B) temperature (°C)
Actual value = value displayed
Inverter compressor discharge (T7C1) temperature (°C)
Actual value = value displayed
Outdoor heat exchanger gas pipe (T5) temperature (°C)
Actual value = value displayed
Compressor inverter module internal (Ntc) temperature (°C)
Actual value = value displayed
Inverter module heatsink (T9)temperature (°C)
Actual value = value displayed
Outdoor heat exchanger liquid pipe (TL) temperature (°C)
Actual value = value displayed
Compressor suction (T7) temperature (°C)
Actual value = value displayed
Discharge superheat degree (°C)
Actual value = value displayed
Actual value = value displayed
Actual value = value displayed × 24
Actual value = value displayed × 4
Compressor discharge pressure (MPa)
Actual value = value displayed × 0.1
Compressor suction pressure (MPa)
Actual value = value displayed × 0.01
Number of indoor units currently in communication with master unit
Displayed on master unit PCB only
Number of indoor units currently operating
Displayed on master unit PCB only
0-OFF; 1-Condenser; 2-Condenser (Not used);
3-Evaporator; 4-Evaporator (Not used)
2~4-Startup control; 6-PI control;
0: 0 Pa; 1: 20Pa; 2: 40Pa; 3: 60Pa; 4: 80Pa.
Actual value = value displayed
Actual value = value displayed - 25
Actual value = value displayed × 10
Actual value = value displayed × 2
Number of indoor units for cooling operation
Actual value = value displayed
Number of indoor units for healing operation
Actual value = value displayed
Number of high temperature hydronic modules running
Actual value = value displayed
Total capacity of indoor units for cooling operation
Total capacity of indoor units for heating operation
Total capacity of high temperature hydro modules running
Power limitation mode settings
Most recent error or protection code
“--“ is displayed if no error or protection events
have occurred since start-up
Notes:
1. The fan speed index is related to the fan speed in rpm and can take any integer value in the range 1 (slowest) to 30 (fastest).
2. Silent mode:
0: night silent time 6h/10h; 1: night silent time 6h/12h; 2: night silent time 8h/10h; 3: night silent time 8h/12h; 4: no silent mode; 5: silent mode;
6: super silent mode.
3. Te: Low pressure equivalent saturation temperature (°C) Tes: Target Te value. Tc: High pressure equivalent saturation temperature (°C) Tcs: Target Tc value.
