Milnor 36026V7Z User Manual

Chapter 4. Troubleshooting
4.2.1.
4.2.1.1. UMTGU A .x)
tion and V3 Connectio
Outputs
M ilTouch 3 (W I 3
Table 11: Output V3 Func n
Label
Function Connec tion om onC m nu r S bbe
O-0
Chemical 1 M2-1
O-1
Chemical 2 2-M 2
O-2
Chemical 3 M2-3
O-3
Chemical 4 M2-4
O-4
Chemical 5 M2-5
O-5
Chemical 6 M2-6
O-6
Chemical 7 M2-7
O-7
Chemical 8 M2-8
M2-10
M2-9
O-8
Hot water valve M3-1
O-9
Cold water valve M3-2
O-10
Sewer drain solenoid M3-3
O-11
Flush valve M3-4
O-12
Cooldown valve M3-5
O-13
Third water valve M3-6
O-14
Reuse drain solenoid M3-7
O-15
Steam valve M3-8
M3-15
M3-16
O-16
Door lock M3-10 & M3-12 -- M3-11
Door unlock (pulsing latch)
M4-4 & M4-5 -- M4-6
O-17
Speed limited (non-pulsing latch) M3-9 & M3-14 -- M3-13
O-18
Operator signal M4-1 & M4-2 -- M4-3
Door u atch) nlock (non-pulsing l
M4-4 & M4-5 -- M4-6
O-19
Speed g latch) limited (pulsin M3-9 & M3-14 -- M3-13
O-20
Alt. decel safety M4-7 & M4-8 -- M4-9
O-21
Tank to machine M4-18 & M4-17 -- M4-16
O-22
Machine to tank M4-15 & M4-14 -- M4-13
O-23
Machine to machine M4-12 & M4-11 -- M4-10
O-24
CW wash speed M5-1 --
O-25
Anti-CW wash speed M5-2 --
Alt. accel safety
M5-3 --
O-26
Inverter S3
M5-3 --
O-27
not used M5-4 --
M5-8
O-28
not used M5-5 --
O-29
not used M5-6
--
PELLERIN MILNOR CORPORATION
43
