Milnor 36026V7Z User Manual

Chapter 4. Troubleshooting
4.2.1.2. MilTouch 2 (WUMTGUIA 2.x)
Table 12: Output Function and Connection
Label
Function Connection Common Snubber
O-0
Chemical 1 M2-1
O-1
Chemical 2 M2-2
O-2
Chemical 3 M2-3
O-3
Chemical 4 M2-4
O-4
Chemical 5 M2-5
O-5
Chemical 6 M2-6
O-6
Chemical 7 M2-7
O-7
Chemical 8 M2-8
M2-10
M2-9
O-8
Hot water valve M3-1
O-9
Cold water valve M3-2
O-10
Sewer drain solenoid M3-3
O-11
Flush valve M3-4
O-12
Cooldown valve M3-5
O-13
Third water valve M3-6
O-14
Reuse drain solenoid M3-6
O-15
Steam valve M3-7
M3-15
M3-16
O-16
Door lock M3-10 & M3-12 -- M3-11
O-17
Door unlock M3-9 & M3-14 -- M3-13
O-18
Operator signal M4-1 & M4-2 -- M4-3
O-19
Speed limited (reserved) M4-4 & M4-5 -- M4-6
O-20
Recirculation pump (reserved) M4-7 & M4-8 -- M4-9
O-21
Tank-to-machine (reserved) M4-18 & M4-17 -- M4-16
O-22
Machine-to-tank (reserved) M4-15 & M4-14 -- M4-13
O-23
Machine-to-machine (reserved) M4-12 & M4-11 -- M4-10
O-24
Inverter S1 M5-1 --
O-25
Inverter S2 M5-2 --
O-26
Inverter S3 M5-3 --
O-27
Inverter S4 M5-4 --
O-28
Inverter S5 M5-5 --
O-29
Inverter S6 M5-6
M5-8
--
PELLERIN MILNOR CORPORATION
44
