Maintenance Manual > Adjustment Items > Adjustment Function > 500mm SQUARE
Model CJV30/TPC Issued 2008.08.04 Revised 2009.06.30 F/W ver. 1.00 Remark
1.1
4.2.8 500mm SQUARE
Function
Adjusts the working distance in the X direction in cutting operation.
Is used to check the distance when the parameter has been initialized, when the position aberration of the feed
direction has occurred during cutting operation, or when plotting cannot be carried out in accordance with the
specified distance.
Procedure
1. Set media, and attach the supplied pen to the cut head carriage.
2. Press [TOOL] with CUT MODE <Local> to set to [PEN].
3. Select [500mm SQUARE] from the operation menu.
4. Plot a square pattern.
[]: Compensation value is cleared.
[]: Pattern drawing
[]: To the screen for compensating
*If there is not enough space for the plotting on the media, Step
6 is displayed and the plotting is not performed.
5. Measure the length of X (feed direction), and work out a
compensation value.
Equation: Measured value (mm) - 500 (mm)
= Compensation value (Input value)
*unit: 0.1 (mm)
<LOCAL.C> [#01]
CUT ( 30/ 60/ 0.30)
SPD PRS OFS
[PEN] 30 60 0.30
[TOOL]
<LOCAL.1> [#01]
FUNCTION
#ADJUST <ent>
#ADJUST /CUT
500mm SQUARE <ent>
#500mm SQUARE
CLEAR < >DRAW
Pattern drawing
Distance compensation value
500 mm
500 mm
Y (scan direction) can be displayed on LCD, but it
cannot be input.
