MIMAKI JV5 Series Maintenance Manual

© 2009 MIMAKI ENGINEERING CO.,LTD.
4.2.11 P.1
1
2
3
4
5
6
7
8
R.1.2
Maintenance Manual > Adjustment Items > Adjustment Function > [PHOTO SENSOR] SENSOR LV.
Model CJV30/TPC Issued 2008.08.04 Revised 2009.06.30 F/W ver. 1.20 Remark
1.2
Rev.
4.2.11 [PHOTO SENSOR] SENSOR LV.
 Function
Carries out automatic compensation of output value so that the mark sensor on the cut head carriage can perform read
operation correctly.
This operation is carried out in the case where the read operation by the mark sensor is unworkable.
(“User menu” also has the same function.)
 Procedure
1. Set media mentioned above directly below the mark sensor, and
set the media clamp to “HIGH”.
2. Select [#PHOTO SENSOR] from the operation menu.
3. Select the [SENSOR LV.] and press [ENTER].
[]/[]: Changes items
[ENTER]: Finalizes (To the next compensation screen)
4. Register an optimum value (automatically displayed).
CJV30 will automatically select an optimum value.
Therefore, wait until the display shows a fixed value and then
enter the value.
[ENTER]: Registers
 The registration mark detection can not be achieved correctly under such conditions that there is any
print or stain in the area scanned by the sensor. To avoid such problem, use unprinted or unstained white
paper under the sensor.
 Set the media used, or lay and set three sheets of copy paper on top of another.
Set unstained white paper (as specified above).
<LOCAL.1> [#01]
FUNCTION
#ADJUST <ent>
#ADJUST /CUT
PHOTO SENSOR <ent>
#PHOTO SENSOR
SENSOR LV.
POSITION
#PHOTO SENS./ LV.
OUT: 0070 IN: 0780
 The display may not become so steady that it keeps
showing only one fixed number. In that case, press
the [ENTER] key when the value of the high-order
digit on the display is fixed.
 Pressing [FUNCTION] will release the heads from
the drive.
