Maintenance Manual > Operating Principle > Basic Operation > Detection of a Media Width
Model CJV30/TPC Issued 2008.08.04 Revised 2008.09.17 F/W ver. 1.20 Remark
1.1
1.1.4 Detection of a Media Width
Indication on LCD
Processing sequence
Step Processing Description
Indication
on LCD
1 Connection of the cut head 1. Refer to "1.1.6 Operation for Connecting the Heads" .
2 Media right end detection 1. After moving the cut head carriage to the position of the first pinch
roller, use the pinch roller detection sensor to detect the right edge of
media.
• When detection is impossible or the number of pinch rollers is not
recognized, the display shows [ERROR50 MEDIA DETECT].
Raise the lever to cancel the error.
3 Clamp pressure switching 1. Refer to "1.1.5 Clamp Pressure Switching" .
4 Media left end detection 1. Move the cut head carriage left and use the pinch roller detection
sensor to detect the right edge of media.
• When detection is impossible or the number of pinch rollers is not
recognized, the display shows [ERROR50 MEDIA DETECT].
Raise the lever to cancel the error.
5 Stand by of head carriage 1. Move the head carriage to the standby position of the cut head.
The operation for detecting a media width will be discontinued, if the clamp lever is placed on the UP position
during the operation. (Only during Step 3 above)
A display during the print
media detection
DETECTING MEDIA NOW
PLEASE WAIT
