Maintenance Manual > Operating Principle > Ink System > Supply Cartridge Control and Selection
Model CJV30/TPC Issued 2008.08.04 Revised 2010.11.05 F/W ver. 2.50 Remark
1.2
Rev.
1.3.3 Supply Cartridge Control and Selection
 Supply cartridge control
 Cartridge status indicated by LEDs
 Selection and determination of the supply cartridge for the 4-color ink set
 supply cartridge switching selection timing
 At power-on
 When an error occurs in the currently selected cartridge
 When a cartridge with higher priority than the currently selected cartridge is inserted
 Switching is not executed during printing or cleaning but executed when the printer has returned to LOCAL mode.
No. Item Description
1 For the 4-color ink set  The printer uses two ink cartridges for 1 supply system (1 nozzle row) and can mount 8
cartridges in total.
 1 supply cartridge is assigned to 1 supply system. The cartridge with less amount of
remaining ink is used first by toggle switching.
 Switching between cartridges for ink supply occurs under any of the following
conditions:
• “INK END” during printing
• “INK NEAR END” during filling
• Ink IC warning
• When the cartridge is removed
• When executing Ink use-up cleaning
2 Except for the 4-color ink set
(filling 6-color, 6-color +
white, 7-color, 8-color ink
set)
 Since there is 1 ink cartridge per supply system, all 8 cartridges are supply cartridges.
LED Status Explanation
Green Lit Supply cartridge
Red Blink INK END, INK NEAR END, Expiration:1MONTH
Lit  NO CARTRIDGE
 WRONG INK IC
Errors related to PIC, namely, NON-ORIGINAL INK, WRONG INK IC, Kind of INK,
Color of INK, WRONG CARTRIDGE and Expiration:2MONTH
 INK REMAIN ZERO
A cartridge having no remaining ink after execution of ink use-up cleaning (only in 4-color use).
