2. Status indicator
Green: All the tests are passed, and the equipment operates properly.
Red: Failure is detected on the equipment.
3. Display screen
4. Soft keys
They are corresponding with the soft key labels located immediately above. The labels of the soft keys change
according to the current operating mode. For Pro, there are five soft keys while for Public, there are three.
5. Shock button
Press this button to deliver a shock to the patient.
6. Handle
7. Power ON/OFF button
Press this button to turn on or off this equipment.
8. Optical sensor
9. Microphone
2.3.2 Side View
1. Speaker
2. USB connector
3. ECG: ECG cable connector (for Pro only)
