Mindray BeneHeart D1 User Manual

E-2
E.3 Device Labelling
Check the labels provided by the manufacturer or the healthcare facilities are present and legible.
 Main unit label
 Integrated warning labels
E.4 Patient Leakage Current
Patient leakage currents are measured between a selected applied part and mains earth. All measurements have a true
RMS only
The following outlet conditions apply when performing the Patient Leakage Current test.
 normal polarity (Normal Condition)
 reverse polarity (Normal Condition)
 normal polarity with open neutral (Single Fault Condition)
 reverse polarity with open neutral (Single Fault Condition)
 normal polarity with open earth (Single Fault Condition)
 reverse polarity with open earth (Single Fault Condition)
LIMITS
For CF applied parts
 10A in Normal Condition
 50A in Single Fault Condition
For BF
applied parts
 100A in Normal Condition
 500A in Single Fault Condition
E.5 Mains on Applied Part Leakage
The Mains on Applied Part test applies a test voltage, which is 110% of the mains voltage, through a limiting resistance,
to selected applied part terminals. Current measurements are then taken between the selected applied part and earth.
Measurements are taken with the test voltage (110% of mains) to applied parts in the normal and reverse polarity
conditions
The following outlet conditions apply when performing the Mains on Applied Part test.
 Normal Polarity
 Reversed Polarity
