2
]
The current settings will appear.
Press the button to go to the setting screen.
[
1
]
Select "Night setback" from the Main menu (refer to page 17), and press
the button.
This control starts heating operation when the control object group is stopped and the room temperature drops below the pre-
set lower limit temperature. Also, this control starts cooling operation when the control object group is stopped and the room
temperature rises above the preset upper limit temperature.
The Night setback function is not available if the operation and the temperature setting are performed from the remote control-
ler.
If the room temperature is measured by the air-conditioner's suction temperature sensor, the accurate temperature may not
be obtained when the air-conditioner is inactive or when the air is not clean. In this case, switch the sensor to a remote sensor
(PAC-SE40TSA/PAC-SE41TS-E) or a remote control sensor.
[
3
]
Move the cursor to the desired item with the
F1
or
F2
button out of Night
setback No (disable)/Yes (enable), Temp. range, Start time, or Stop time.
Change the settings with the
F3
or
F4
button.
Administrator passwaord setting. (Refer to page 51)
• Temp. range:
The lower limit temperature (for heating operation) and the
upper limit temperature (for cooling operation) can be set. The temperature
difference between the lower and upper limits must be 4°C (8°F) or more. The
settable temperature range varies depending on the connected indoor units.
• Start/Stop time:
settable in 5-minute increments
* Press and hold the button to rapidly advance the numbers.
Press the button to save the settings.
A conrmation screen will appear.
Navigating through the screens
• To go back to the Main menu .................. button
• To return to the previous screen .............. button
