Mitsubishi Electric Mr.Slim PAR-30MAA User Manual

48
Initial setting
Display detail setting
F1 F2 F3 F4
Display details
Cursor
Change
Select:
Clock
Temperature
Room temp.
Auto mode
No 24h
Yes / No
Yes / No
F1 F2 F3 F4
Main menu:
Initial setting menu
Cursor Page
Main/Sub
Clock
Main display
Contrast
Display details
F1 F2 F3 F4
Clock display
Cursor Cursor
Select:
Clock
12h disp.
AM/PM disp.
Yes No
Main
Sub
Button operation
[
2
]
[
1
]
Move the cursor to the "Display details" with the
F1
or
F2
button, and
press the button.
Select "Initial setting" from the Main menu (refer to page 17), and press the
button.
Move the cursor to the "Clock" with the
F1
or
F2
button, and change the
setting with the F4 button.
Clock
[
3
]
Move the cursor to the "Clock", "12 disp." or "AM / PM disp." with the
F1
or
F2
button, and change the setting with the
F3
or F4 button.
The factory settings are "Yes" (display) and "24h" format.
• Clock display: Yes (Time is displayed on the Main display)
No (Time is not displayed on the Main display)
• Display format: 24h : 24h format
12h : 12h format
• AM / PM display (Effective when the display format is 12-hour):
AM / PM before the time [AM12:00]
AM / PM after the time [12:00AM]
Press the button to save the settings.
Note: Time display format will also be reflected on the time and schedule
setting display. The time is displayed as shown below.
12-hour format : AM12:00 – AM1:00 – PM12:00 – PM1:00 – PM11:59
24-hour format : 0:00 – 1:00 – 12:00 – 13:00 – 23:59
Navigating through the screens
• To go back to the Main menu .................. button
• To return to the previous screen .............. button
