5-102 Maintenance parts
5 Maintenance and Inspection
5.5 Maintenance parts
The consumable parts that must be replaced periodically are shown in Table 5-6, and spare parts that may be
required during repairs are shown in Table 5-7. Purchase these parts from the dealer when required. Some Mit
-
subishi-designated parts differ from the maker's standard parts. Thus, confirm the part name, robot arm and con
-
troller serial No. and purchase the parts from the dealer.
Table 5-6 ： Consumable part list
Table 5-7 ： Spare parts list
No.
Part name Type Usage place Q'ty Supplier
1 Timing belt J1 axis 1
Mitsubishi Electric
2J3 axis1
3J4 axis1
4J5 axis1
5J6 axis1
6 Grease Reduction gears of each axis An needed
7 Lithium battery ER6 Inside the CONBOX cover 3
No. Names
Usage place
Q'ty Supplier
RV-4F series (common)
1 AC servo motor J1, J2 axis 2
Mitsubishi Electric
2J3 axis 1
3 J4, J5 axis 2
4J6 axis 1
RV-4F (Standard arm type)
5 Reduction gears J1, J2 axis 2
Mitsubishi Electric
6J3 axis 1
7J4 axis 1
8J5 axis 1
9J6 axis 1
10 Various seals Application area at the time of shipment 1
RV-4FL (Long arm type)
11 Reduction gears J1 axis 1
Mitsubishi Electric
12 J2, J3 axis 2
13 J4 axis 1
14 J5 axis 1
15 J6 axis 1
16 Various seals Application area at the time of shipment 1
RV-7F series (common)
17 AC servo motor J1, J2 axis 2
Mitsubishi Electric
18 J3 axis 1
19 J4, J5 axis 2
20 J6 axis 1
RV-7F (Standard arm type)
21 Reduction gears J1, J2 axis 2
Mitsubishi Electric
22 J3 axis 1
23 J4 axis 1
24 J5 axis 1
25 J6 axis 1
26 Various seals Application area at the time of shipment 1
RV-7FL (Long arm type)
27 Reduction gears J1 axis 1
Mitsubishi Electric
28 J2, J3 axis 2
29 J4 axis 1
30 J5 axis 1
31 J6 axis 1
32 Various seals Application area at the time of shipment 1
