Confirming the product
2Unpacking to Installation
2 Unpacking to Installation
2.1 Confirming the product
The standard configuration of the robot arm, part of the purchased product, is shown in Table 2-1.
Confirm the parts.
Users who have purchased optional products should refer to the separate "Standard Specifications".
Table 2-1 ： Standard configuration
No. Part name Type Qty. Remarks
RV-4F series
1 Robot arm RV-4FM-SExxxx
RV-4FLM-SExxxx
Each 1 unit SExxxx means the following.
SExx01: Chemical-resistant specifica
-
tions
SExx02: Food machinery grade H1
grease specifications
2 Guarantee card 1 copy
3 Installation bolts Ｍ8 x 40 4 pcs. For robot arm installation
4 Spring washer for installation bolts For M8 4 pcs.
5 Plain washer for installation bolts For M8 4 pcs.
6 Grease nipple WA-610 6 pc. For SExx01
5 pc. For SExx02
7 Suspension fitting 2 sets
8 Suspension fitting installation bolt Ｍ6 x 20 6 pcs.
9 Plain washer for suspension fitting installa
-
tion bolt
For M6 6 pcs.
10 Eye bolt M10 4 pcs.
11 Nut for eye bolt For M10 4 pcs.
12 Fixing plate 1 set
13 Fixing plate installation bolt Ｍ15 x 12 4 pcs.
14 Plain washer for fixing plate For M5 4 pcs.
RV-7F series
1 Robot arm RV-7FM-SExxxx
RV-7FLM-SExxxx
Each 1 unit SExxxx means the following.
SExx01: Chemical-resistant specifica
-
tions
SExx02: Food machinery grade H1
grease specifications
2 Guarantee card 1 copy
3 Installation bolts Ｍ8 x 40 4 pcs. For robot arm installation
4 Spring washer for installation bolts For M8 4 pcs.
5 Plain washer for installation bolts For M8 4 pcs.
6 Grease nipple WA-610 5 pcs. For SExx01
4 pcs. For SExx02
7 Suspension fitting 2 sets
8 Suspension fitting installation bolt Ｍ8 x 25 4 pcs.
9 Plain washer for suspension fitting installa
-
tion bolt
For M8 4 pcs.
10 Eye bolt M10 4 pcs.
11 Nut for eye bolt For M10 4 pcs.
12 Fixing plate 1 set
13 Fixing plate installation bolt Ｍ15 x 12 4 pcs.
14 Plain washer for fixing plate For M5 4 pcs.
