DASH PANEL
The dash panel is not a double-walled structure
consisting of the dash panel and dash panel
reinforcement as in former models but is made
Furthermore, the hood latch bracket has a closed
cross section to improve strength.
(2) A large headlamp housing is used to improve
strength.
from a single thick plate. The engine compartment has
effectively expanded while preserving rigidity.
REAR END PANEL
The rear end panel is mounted on the outside of rear
lamp housings so the panel replacing work becomes
easier.
31F0096
-
BODY -
Main
Body
BODY SHELL
HEADLAMP SUPPORT
structure as shown below is used with the large soft
fascia which consists of the front bumper, skirt panel and
header panel moulded into one unit.
(1) A large and very rigid front end upper bar is used.
Rear lamp housing
Rear end panel
31F0013
Front end upper bar
Hood latch bracket
31 F0124
30F0064
Front end upper bar
Rear lamp housing
Rear end panel
Dash panel
Foot rest bracket
Front floor side sill, inner, front
Dash panel crossmembe
Muffler hanger reinforcement
To Next Page
