The heater and air conditioning have outstanding cooling
and heating performance and use a small amount
refrigerant system.
FEATURES
Improvement of
visual recognition
Improvement of
reliability and
serviceability
Improvement of
performance
Improvement in
performance
SPECIFICA TIONS
doption of air conditioner colour monitor
1. Adoption of a 2-step control system for the condenser and radiator fan speed.
2. Flange fitting of the receiver piping joints.
3. Belt protection by belt lock controller when compressor is locked.
1. Adoption of multi-flow type condenser.
2. Adoption of small amount refrigerant system.
3. Adoption of heater unit with maximum cool by-pass.
1. Adoption of a multi-flow type condenser.
2. Adoption of a small amount refrigeration system.
ELECTRICAL - Heater and Air Conditioning
7-33
HEATER AND AIR CONDITIONING
GENERAL INFORMATION
Items Specifications
Heater unit
Type Three-way-flow full-air-mix system
Heater control switch Push button type
Compressor
Model Scroll type (FX-105VS)
Refrigerant unit lubricant cm
3
(cu.in.) FREOL S-83 or SUNISO 5GS 160 +20 / -0 (9.8 +1.2 / -0)
V-belt size mm (in.) 1,150 (45.3)
Condenser
Type Multi-flow type
Dual-pressure switch
\
High pressure switch kPa (kg cm
2
, psi) OFF: 2,700 (27, 384) ON: 2,100 (21, 299)
Low pressure switch kPa (kg cm
2
, psi) OFF: 210 (2.1,30) ON: 235 (2.35, 33)
Freezer prevention ºC (ºF) Fin temperature thermostat
OFF: -2 (28.4) ON: 2 (35.6)
Refrigerant and quantity g (oz) R-12 MAX 770-870 (27-31)
