1-8
ENGINE - Cooling System
COOLING SYSTEM
The cooling system uses a water cooling pressure
control circulation system and it has the following
features.
• The cooling (radiator) fan uses a motor driven sys-
tem. The fan is driven by the motor only when
needed to efficiently control the cooling water
temperature and reduce engine output loss .
• The cooling fan is a full shroud type for improved
cooling performance.
The two step control system is used for the motor
driven cooling fan and condenser fan for less fan
noise, reduced vehicle vibration and improved
cooling when the engine is idling. (Refer to GROUP
7 - Condenser Fan and Radiator Fan Control for fan
speed operation mode.)
SPECIFICATIONS
Items Specifications
Cooling fan
Type Motor driven system
Water pump
Type Centrifugal type impeller
Drive method Timing belt
Thermostat
Type Wax type
Open valve temperature °C (ºF) 76.5 (170)
Radiator
Coolant capacity (including that in
condenser tank) dm
3
(U.S. qts., Imp. qts.) 8.0 (8.5, 7.0)
Condenser tank capacity dm
3
(U.S. qts., Imp. qts.)
Full 0.65 (0.69, 0.57)
Low 0.25 (0.25, 0.22)
Type Corrugated type
