18F0078
Since the door glass is sucked out by the vacuum
caused by air flow when driving at high speed, a full
glass catch is mounted to the weather-strip holder in
order to press the door glass in place. As a result, a
good seal between the drip line weather-strip and the
door glass is assured and the sucking noise when
driving at high speed is shut down.
Cross section
-
DOORS
Full glass catch
Door window glass-
Drip line weathe
-strip
Weather-strip
holder
4-10 BODY - Air Pressure Noise Reduction
I
Doors
DOOR PANEL
sashless door is used. Furthermore, rigidity of the
outside panel is improved by efficient use of a light-
weight side door beam made of pipe and reinforce-
ments.
Side door beam
Beltline outer reinforcement
Door mirror reinforcement
Hinge rein
orcement
Beltline inner reinforcement
Door latch reinforcement
18F0209
