Mitutoyo DP-1VR User Manual

- 23 -
OPERATION
● Power ON
● Data input
Data can be input with the foot
switch interval timer or the
'DATA' key
● Data cancel
Cancel previous input data.
● Data all clear
Clear all input data
● Time printing
Print date and time
● Statistical calculation
Statistically calculates input data.
(This function is not available in
mode 0)
POWER
DATA
DATA
CE
CL
PRINTER ON/OFF
+ DATA
STAT
* DP-1VR *
* MODE 1 *
DATE 2000/ 2/ 2
TIME 13: 35
Take data from the measuring
tool and print.
1 12.23 mm
2 26.25 mm
* CANCEL *
* CLEAR *
DATE 2000/ 2/ 2
TIME 13:36
PART NO.
DATE 2000/ 2/ 2
TIME 13: 35
NAME:
*RESULT*
N56
MAX 81.26 mm
MIN 25.66 mm
R 55.60 mm
X 54.23 mm
σn 12.5635 mm
σn-1 13.5897 mm
Function Operation Print
2. Basic Operation 1
Basic operations that do not have set limits are shown.
Similar operations are conducted in Mode0, Mode1, Mode2 also.
2.1 Data input, cancel, clear
