OPERATION
Power ON
Initiate measurement of a sub-
group
Transfer a subgroup to measuring
mode.
Data receiving
(Subgroup measure mode)
Data cancel
Cancels prior input data.
('CL' key pressed during
measurement of a subgroup)
Subgroup data is all cleared.
Data in subgroup is all cleared,
and are measured again from No.1
data.
('CL' key pressed during
measurement of subgroups)
Time printing
Finish measurement of subgroup
and calculate X-R of subgroup.
(Normal sub-group measure mode
is finished)
Stop measurement of subgroup, and
release subgroup measure mode.
(Subgroup measure mode forced
finish)
POWER
TOL.LIMIT
DATA
DATA
DATA
CE
CL
PRINTER ON/OFF+
DATA
STAT
TOL.LIMIT
* DP-1VR *
* MODE 3*
DATE 2000/ 2/ 2
TIME 13: 35
SUB GR. NO.1
Print data received in from
measuring equipment.
1 12.00 mm
2 26.25 mm
3 32.56 mm
* CANCEL *
* CLEAR SUB DATA*
DATE 2000/ 2/ 2
TIME 13: 35
X 0.92335 mm
R 2.77568 mm
PART NO.
DATE 2000/ 2/ 2
TIME 13: 35
NAME
* EXIT SUB GR. *
Function Operation Print
4. Mode 3
Example mode3 operation
